The easiest way to install Mac OS X on your PC.
Now with support for Mountain Lion.
Requirements:
- Kakewalk (Free): Kakewalk is a Mac app that basically works in two parts. First, it modifies the official Mac OS X Lion installer, and writes it onto a USB drive. You can then use this Kakewalk USB drive to run the Mac OS X Lion installer on a PC.
Secondly, once you install Mac OS X Lion with your Kakewalk USB drive, Kakewalk will install a bunch of Hackintosh-specific kexts and configuration files in the background. This will enable your Hackintosh to work with full functionality, immediately after the initial installation of Lion. - A PC with supported hardware: Here's the catch: Kakewalk only works with a very small number of Gigabyte motherboards (barely 30 of them). In comparison, the standard Unibeast method supports several hundred different motherboards. The Kakewalk website includes a compatibility list, but it's missing a few motherboards; the easiest way to find out whether your motherboard is supported is to actually download Kakewalk, start the app, and check.
- An existing Mac OS X installation: Kakewalk is a Mac app, so you need a computer with Mac OS X to run it. You could use a real Mac, if you own one.
- Mac OS X Lion ($30 or $70): The method used by this guide requires that you have a copy of the Lion installer app ($30) from the Mac App Store, or in the Lion USB Thumb Drive ($70) sold by Apple. The Mac App Store is available in Mac OS X version 10.6.6 or higher.
- An empty USB drive (8 GB or larger): The USB drive used for Kakewalk must be at least 8 GB in size. Since Kakewalk will erase all of the files on your USB drive, make sure to back up its contents first. You can reuse this USB drive for normal stuff after you finish installing Lion.
1. Run Kakewalk
Download Kakewalk, and unzip the downloaded file (by double-clicking it). Inside the Kakewalk folder, start "Kakewalk.app". It will ask you for a password. Enter your password for Mac OS X. Then, if you haven't already, plug your USB drive into your computer.
At the Kakewalk start screen, choose the option "Create install disk".
I covered these steps in my Snow Leopard guide, but they're worth mentioning again: Open up your Hackintosh, and make sure that the SATA cables for your hard drive and your DVD/Bluray drive are plugged into the 3GB/s SATA ports on your motherboard, not the 6GB/s SATA ports (these should be labeled on the motherboard). On Gigabyte motherboards, the 3GB/s ports are blue while the 6 GB/s ports are white. The 6 GB/s SATA ports simply don't work well with OS X.
NOTE: If your computer is more than 2 years old, it probably won't have any 6GB/s SATA ports.
 |
| Source |
Also, unplug any extra internal hard drives that your computer has, besides the hard drive that you're installing OS X on. (Just unplug the hard drive SATA cables from your motherboard.)
3. Setting up your motherboard's BIOS
The BIOS is basically a settings page for your motherboard. To enter the BIOS on a Gigabyte motherboard, press the delete key when it boots (before the operating system starts).
Go to "Advanced BIOS Features" and set the first boot device to "USB-HDD". You should then set "Hard Disk" as second boot device.
After you finish installing Mac OS X Lion, you should change the first boot device back to "Hard Disk" (this optional, but it will speed up your Hackintosh's boot time).
4. Boot into Kakewalk
Restart your Hackintosh, and plug in your Kakewalk USB drive. If things go well, your computer will boot from the USB drive instead of booting from your normal hard disk. You should see the Kakewalk bootscreen.
Once you reach the bootscreen, Kakewalk will automatically start the Mac OS X Lion installer in a few seconds.
To enter boot flags, manually restart your computer by pressing your computer's power button. Then, once you've booted back into the Kakewalk bootscreen, try typing any necessary boot flags before pressing the enter/return key. Check out this list of common boot flags for reference ( PCIRootUID=0 and -x are two popular boot flags).
5. Install Lion
Continue, and you will eventually come up to a page that asks you for a "destination" for your Mac install. Select the hard drive that you want to install Mac OS X Lion on, and continue.
Restart. You can unplug the Kakewalk USB drive. You should see the Kakewalk bootscreen again. In a few seconds, Lion will start to boot, and you should eventually be led to the Mac OS X setup screen. Fill it out, then mission accomplished!
Once again, if you get a kernel panic/loading error when you try to boot your new Lion installation (or if the installation simply won't start within 10 minutes), you'll need to enter some boot flags.
6. You're done!
7. "Upgrade" your installation [OPTIONAL]
When you first install Mac OS X Lion, it will probably already be on the newest version. You can check what version you have by clicking on the Apple icon on the upper left-hand corner of Mac OS X, and clicking "About This Mac".
If your Hackintosh needs to be updated, all you need to do is download the combo update for the newest version of Mac OS X Lion, and install it. Apple does not directly link to the combo updates on its support site, but you can easily find these combo updates through Google. For instance, if you're looking for the combo update for Mac OS X 10.7.3, simply Google "10.7.3 combo update" (without the quotation marks). The official Apple page will be the first result.
When the combo update finishes installing, don't reboot. Instead, start the Kakewalk app. Your Kakewalk USB drive will include a copy of the Kakewalk app; if you don't have your USB drive available, you can just redownload Kakewalk from the internet. Once Kakewalk is open, click on "Upgrade Installation".
